Rechargeable battery module TRIO-BAT/PB/24DC/12AH

For uninterruptible power supply A6963

The battery module Phoenix Contact TRIO-BAT/PB/24DC/12AH is a 24 V DC energy source with a VRLA-AGM lead-acid battery. It is intended as a battery unit for 24 V DC UPS systems and is used to increase backup capacity and extend the autonomy time of connected equipment.
The module contains a 12 Ah battery and is supplied with pre-assembled connection cables and fuse holders for easy installation in control cabinets or on a DIN rail. The backup time depends on the load level.

Main parameters:

• nominal voltage 24 V DC
• battery capacity 12 Ah
• VRLA-AGM technology
• installation in a cabinet or on a DIN rail
• pre-assembled cables and fuse holders

A6963 power supply is not included, must be ordered separately.
