Thermometer for 2 external probes + 2x 0-5V inputs with display

Thermometer is designed for record of temperature. Values are stored to a non volatile electronic memory. Data transfer to the personal computer for further analysis is performed via USB, RS232, GSM or Ethernet interface by means of a proper adapter.

The device includes Traceable calibration certificate with declared metrological traceability of etalons is based on requirements of EN ISO/IEC 17025 standard.

For communication with the PC must be from Optional accessories ordered USB adapter, LAN adapter or COM adapter or start/stop magnet if is needed to control logging the other way than directly from computer.

  • code
    S0541
  • Warranty
    3 years

Technical data

Operating temperature range -30 to +70°C
Accuracy of temperature input without probe ±0.2°C from -50 do +100°C
±0.2% from reading from +100 to +260°C
±0.4% from reading from –90 to –50°C
Resolution of the reading 0.1°C
Accuracy of 0-5Vdc inputs ±0.2% FS
Real time clock year, leap year, month, day, hour, minute, second
Data logging interval adjustable from 10s to 24h
Display and alarm refresh each 10 s
Total memory capacity 32000 temperature values in noncyclic logging mode
Data logging mode noncyclic - data logging stops after filling the memory
cyclic - after filling memory oldest data is overwritten by new
Dimensions 93x64x29mm
Power Lithium battery 3,6V, size AA
Typical battery life 5 years
Battery life in continuous on-line mode with interval 1 minute reduced to 70% of the above life
Battery life in continuous on-line mode with interval 10 second 1 year
IP protection IP67 - protected against influence of temporary immersion into water
Weight including battery 130g
Warranty 3 years

Optional accessories and download

Ambient temperature probe, 200-80/E

Ambient temperature probe, 200-80/E

Temperature range: -30 to 80°C
code SN171

Lithium battery 3,6V/AA

Lithium battery 3,6V/AA

code A4203

Accredited temperature calibration

Accredited temperature calibration

code SLU001

KIT - GSM/GPRS modem LP040 with accessories for Sxxxx, Rxxxx loggers

KIT - GSM/GPRS modem LP040 with accessories for Sxxxx, Rxxxx loggers

code KIT-GSM-L
USB adapter

USB adapter

code LP003
Start/stop magnet

Start/stop magnet

code LP004
COM adapter with protection IP65

COM adapter with protection IP65

code LP012
GSM/GPRS MODEM for data loggers of Sxxxx, Rxxxx, Gxxxx families

GSM/GPRS MODEM for data loggers of Sxxxx, Rxxxx, Gxxxx families

code LP040
Transducer USB/RS232 complete

Transducer USB/RS232 complete

code MP006
Antenna for GSM modem

Antenna for GSM modem

code MP009/1
Wall holder for GPRS modem

Wall holder for GPRS modem

code MP036
DIN Rail 35mm holder for GPRS modem

DIN Rail 35mm holder for GPRS modem

code MP037
Communication cable for GSM modem

Communication cable for GSM modem

code QMS2901
One time fee for using M2M server - applied for each data logger with modem

One time fee for using M2M server - applied for each data logger with modem

code SLU302

wall holder for datalogger

wall holder for datalogger

code F9000
Self Adhesive Dual Lock

Self Adhesive Dual Lock

code MD036

COMET Database

COMET Database

code CDB
Software for COMET TPrints and GSM modems

Software for COMET TPrints and GSM modems

code SWR001

Female ELKA3008V connector

Female ELKA3008V connector

code K1321
