IoT Wireless Temperature Sensor for 4 external Pt1000 probes with ELKA connector, LoRaWAN network

The W0941 sensor with LoRaWAN network output measures temperature from four external Pt1000 probes on the cable and can be installed directly in the measured environment thanks to its IP65-rated enclosure. LoRa devices are powered by a replaceable battery with a lifespan of up to 10 years (3 years standard). External power with optional accessories is also available.

Measured values are transmitted wirelessly at adjustable intervals (from 5 minutes to 24 hours) to the COMET Cloud storage, where they are accessible to users via computer or mobile device. The sensors offer remote configuration from the COMET Cloud and feature the capability to monitor up to two alarm thresholds, with any exceedance signaled by an alert sent to the user.

Key Features

Wireless transmission of measured values and alarm states
Battery-powered with low battery indicator (battery life up to 10 years) and external power option
Remote device configuration via COMET Cloud
IP65-rated enclosure
Calibration certificate with declared metrological traceability of standards according to CSN EN ISO/IEC 17025
Preconfigured Gateway available as an accessory at extra cost. For easy use, we offer several types of preconfigured LoRaWAN gateways that are fully prepared for communication with COMET Cloud and our sensors. This option simplifies the setup process and saves time for users

code

W0941
Warranty

3 years

Technical data

Measured value

Temperature

TEMPERATURE SENSOR - external probe Pt1000

Measuring range -90 to +260 °C

Accuracy ±0.2 °C in the range -90 to +100 °C; ±0.2 % from reading from +100 to +260 °C

Resolution 0.1 °C

Response time t90 of temperature measurement (temperature step 20°C, air flow approximately 1m/s) 10 minutes

GENERAL TECHNICAL DATA

Operating temperature -30 to +60 °C

Channels 4x external temperature probe, ELKA connector

Message transmission interval adjustable 5-10-15-20-30 minutes, 1-2-3-4-6-8-12-24 hours

Operating frequency Europe 863-870 MHz

Maximum transmission power 25 mW (14 dBm)

Typical range of transmitter 15 km in the field, 2 km in the city (sensor in building)

Antenna internal, gain 2,15 dBi

Maximum receiver sensitivity -136 dBm @BW=125 kHz, SF=12

Power Lithium battery 3.6 V, C size, capacity 8.5 Ah

Protection class IP65

Dimensions 179 x 134 x 45 mm without connectors

Weight (including batteries) 350g

Warranty 3 years
